EickLoxx Small Contour Plate Set

https://www.eickemeyer.de//web/image/product.template/110734/image_1920?unique=0518e90

€ 0.00 0.0 EUR € 0.00

€ 1,795.00

Price visible after login

Item No. 197900

    This combination does not exist.


    The EickLoxx Small Contour plate set includes various anatomically preformed osteosynthesis plates for the treatment of fractures of the distal radius and femur, ilium, acetabulum and for arthrodesis of the carpus and tarsus. It complements the cut-to-size plates of the EickLoxx Small osteosynthesis system and is therefore also designed for the treatment of cats and dogs up to 15 kg. The instruments from the EickLoxx Small osteosynthesis system are used in a similar way.

    The titanium plates of the EickLoxx Small Contour plate set are available in two plate thicknesses: The 2.2 mm plates (yellow, green and magenta) can be locked polyaxially with the 1.7 mm and 2.3 mm screws and the 3.0 mm plates (light blue) optionally with the 2.7 mm, 3.5 mm and 4.0 mm screws of the EickLoxx series.

    Despite contouring, the panels can be bent as required using the cabinet iron and / or the panel bending pliers with rollers and shortened using the cutting pliers.

    The sieve tray with the EickLoxx Small Contour plates fits into the container Art. No. 185555 on the two sieve trays of the EickLoxx Small system.

    Features

    • EickLoxx bone plates minimise contact with the periosteum and thus reduce the iatrogenic stress on bone perfusion that is common with conventional compression plates
    • Preservation of perfusion significantly reduces the risk of infection and accelerates bone healing
    • Resistance to infection is also increased by the biocompatibility of titanium and the absence of friction wear

    Technical properties

    • Titanium alloy for maximum biocompatibility
    • Multidirectional locking bi- and monocortical
    • Eliminates abrasion
    • Geometry optimised strength
    • Bendable in three planes

    Biological advantages

    • Reduces damage to the vascularisation
    • Increased resistance to infection
    • Accelerated healing

    Set complete, consisting of:

    • EickLoxx Small Contour Sieve Tray
    • EickLoxx Small Contour 2.2 mm L-plate left, 9-hole, gold
    • EickLoxx Small Contour 2.2 mm L-plate right, 9-hole, gold
    • EickLoxx Small Contour 2.2 mm T-plate, 10-hole, gold
    • EickLoxx Small Contour 2.2 mm Y-plate, 10-hole, gold
    • EickLoxx Small Contour 2.2 mm hockey plate left, 9-hole, gold
    • EickLoxx Small Contour 2.2 mm hockey plate right, 9-hole, gold
    • EickLoxx Small Contour 2.2 mm C-plate, 4-hole, green
    • EickLoxx Small Contour 2.2 mm C-plate, 5-hole, green
    • EickLoxx Small Contour 2.2 mm C-plate, 6-hole, green
    • EickLoxx Small Contour 2.2 mm cricket plate, 4+4 holes, magenta
    • EickLoxx Small Contour 2.2 mm cricket board, 6+6 holes, magenta
    • EickLoxx Small Contour 2.2 mm cricket board, 8+8 holes, magenta
    • EickLoxx Small Contour 3.0 mm L-plate left, 9 holes, light blue
    • EickLoxx Small Contour 3.0 mm L-plate right, 9-hole, light blue
    • EickLoxx Small Contour 3.0 mm T-plate, 9-hole, light blue
    • EickLoxx Small Contour 3.0 mm Y-plate, 9-hole, light blue
    • EickLoxx Small Contour 3.0 mm Hockey plate left, 9-hole, light blue
    • EickLoxx Small Contour 3.0 mm hockey plate right, 9-hole, light blue
